Certificates/Standards: | N; |
Monthly Output: | 500sets per month |
Regional: | No.34 Zhenlian Road,FushaTown,Zhongshan City,Guangdong,China |
Packaging Information: | Outer packing: Wooden crate package |
Mode Of Payment: | T/T L/C D/A D/P |
Delivery Lead Time: | 30 Days |
Main Sales Markets: | North America,Central/South America,Western Europe,Eastern Europe,Australasia,Asia,Middle East,Africa |
Sample Provided: | No |
Sample Policy: | Not provided |
Minimum Quantity: | 1 Set |
Features
- Special load cell with high precision and high standard.
- Program recovery function can reduce operation failures and support multi-segment weight calibration
- No products auto pause function can improve weighing stability and accuracy
- Linear amplitude can be adjusted independently in the running
- Many languages available for global markets.
- 100 programs capacity can meet various weighing requirements and user-friendly help menu contributes to easy operation
Mechanical character
1.1.6L/2.5L hopper, suitable for all kinds of common standard materials, can be used widely
2.Mold making process and uniform design standards contribute to better interchangeability for spare parts
3.Thickened carbon steel machine frame and the whole carbon steel middle standing improve the strength of the machine, making the time for stabilizing weighing shorter.
4.Suitable for dry environment and dry materials production environment, cost-effective.
5.Weighing type for material detection is available, which can make accurate control of feeding time & material thickness and ensure weighing accuracy
Application
It is suitable for weighing leisure foods such as candy, seeds, jelly, pet foods, puffy foods, pistachio, peanuts, nuts,raisins etc. and big shell nuts, hardwares, dried fruits, frozen foods, snack foods, meatballs and so on.
Product Layout Diagram
Technical specification
Model |
JW-A10 |
JW-A14 |
Identify Code |
A10-1-1T |
A14-1-1T |
Weighing Range |
10-1000g |
10-1500g |
Accuracy |
X(0.5) |
X(0.5) |
Max Speed |
65P/M |
120P/M |
Hopper Volume |
1.6/2.5L |
|
Control Panel |
7''Touch Screen |
|
Options |
Dimple Plate/Timing Hopper/Printer/Reject Device |
|
Driving System |
Step Motor |
|
Power Requirement |
220V/1000W/50/60HZ/10A |
220V/1500W/50/60HZ/10A |
Packing Dimension(mm) |
1620(L)X1100(W)X1110(H) |
1700(L)X1100(W)X1265(H) |
Gross Weight |
380kg |
490kg |
