Starch Mogul Line












Production Capacity

2000~2500kg（Depends on the shape of candy）




Power Consumption

252 kw（Depends on the machine type）




Steam Consumption

1200 kg/h




Steam Pressure

0.8 mpa




Compressed Air Consumption

7 m³/min




Air Pressure

0.8 mpa




Vacuum Water Consumption

2 m³/min




Machine Weight

30000 kg








DRTH-606-II Starch Mogul Line

D&R mogul plant especially producing gummy candies.With high quality,easy operation,working reliable,with high output.The whole plant include kitchen system,mogul plant,starch conditioning system,starch collecting and recycle system,product finishing and ancillary machinery.The plant suits for producing gelatin base candies,foamed candies and so on.What ever your production requirements,D&R has the right solution.We offer different types of depositors to meet to your needs for flexibility and speed.We offer the depositing type with swing,one shot,servo driven for center filled gummies and stripe gummies.





Kitchen System

Material Preparation

The full system including the gelatin dissolving tank,pectin dissolving tank and sugar mixing tank and dissolving tanks,with one control group.D&R also offering the auto-weighing and dissolving system for instead the manual work,and give whole automation system.



Automatic Weighing and Dissolving System

D&R also offering the auto-weighing and dissolving system instead the manual work,and give whole automation system.

This system can weigh raw materials,such as water,sugar,glucose,etc.Then to mix them.After mixing,the mixture will flow down to dissolving tanks.The lower holding tank has a heating coil in it to keep premixing at the correct temperature.The system is available in a sophiticated version with PLC control system and operating screen or a dedicated batch weighing controller.



Cooking System

We are use the tubular cooking system for the gelatin syrup,the full system including coil cooker,vacuum chamber,vacuum system,and butter tank,above tanks with one control group.With automatic steam control valve,and automatic temperature controller,with pid system,with uncooked material recycle system and so on.



Automatic CFA System

After cooking the material,should send the material to the CFA tanks.D&R offers auto CFA system also as the requirement of customers for adding the color,flavor,acid.







Depositing Mogul

Depositing Pump Body



Pump casting is made from hard copper alloy,wear-resisting and corrosion-resistant.Its dimensional is ensured by CNC machining center.There are many models to choose from.Meeting customers demands for diversity.



Distribution Board



Molding is made according to customer's requirements,and its arrangement is designed by engineers to yield the best effects.The molding frame is easy and convenient to be disassembled.









Starch Conditioning System



The starch conditioning system consists with dryer and cooler,the processing of heating and cooling according to vortex heating exchange principle.

The molding starch which is not suit for the requirement of humidity inside the mogul plant is sent to starch drying system through the screw conveyor, the starch be particular estate and suspend on the feeding loam board tunnel in starch dryer, the suspend starch particular exchange the heating with hot air inside the tunnel, hot air takes the humidity of starch; dried starch is sent to cooler by screw conveyor, same, the starch be particular estate and suspend on the feeding loam board tunnel in starch cooler, the suspend starch particular exchanges the heating with cooling air inside the tunnel the starch be the required temperature (under 32 degrees) and humidity(under 7%) and sent back to mogul be filled inside trays.

Using the bag type dust collector for the starch drying and cooling, ensure the starch be recycled completely.





Starch Buffering System



When the new machine starts running, the starch will be fed into here manually for storage. The starch from the mogul, the starch collector and the starch conditioning system will be transported to starch buffering & distribution system, and then transported to the Mogul through the screw conveyor for production.





Finishing System



Oil Coating Machine or Sugar Coating Machine:



• Dimension (LxWxH):1630x1590x1380mm

• Machine weight: 0.7t

• Capability: 1500kg/hour as per 2.5g candy

• Material touch with food be SS304

• Easy operation

• With removable wheels





Curing Room



This is very important part of the gummy candy processing, the candy will be cooled or heated to the requirement moisture content for several hours in the curing room, then can be successful. It is uniform temperature and humidity, easy operation and stable control.









Machine Advantages

* Adopt the international advanced side tray transportation system

* Vibration sieve & twin rotary barrel & Air cleaning system, Lower noise and less dust pollution

* SS316 pump body with 360° warm keeping advantage, which is good at producing high Brix product, saving power consumption,improving efficiency and capacity.

* Piston with jacket sleeve for convenient maintain and higher accuracy

* Whole system is Brushless, solve the safety problems caused by hair loss of brush.

* Machine is easy to clean, and has no sanitary dead corner.



Our Service



* D&R Machinery With Many Years Experience

* High Technology team

* Giving The Whole Project Solution

* Consulting For Candies, Gummy, Chocolate And Its Packing

* Always Giving The Economic Machine

* Better Quality, Better Service After Sales For All Of The Customer



































1.Q:where are your company?

A:The company is located at F12, Shanshan Plaza, Yinzhou District, Ningbo, China.



2.Q:Are you direct factory?

A:We are both manufacturer and technical trading company. We are professional confectionery machine manufacturers with over 20 years in the business operating at the highest industry standards. We’ve built a reputation on engineering, designing and delivering high-performance total-solution confectionery machinery to clients with absolute precision around the world. Certainly,we welcome you to come visit our factory.



3.Q:What are your main products?

A:All kinds of Chocolate making machines, Candy making machines,Swiss roll and layer cake production line, Candy bar production line and Packing machines.



4.Q:Do you have gurantee for your product?

A:We have a full quality control system.Every hardware part must be checked by the quality inspector before the products enter to the warehouse.Our electric elements are all famous brands, most of them are imported. When each machine is finished, we will invite customers to test and run the machine in our factory to ensure the high quality of our machines. Besides, we have CE, and SGS certification.
