Certificates/Standards: | N; |
Monthly Output: | 1000/set |
Regional: | Not provided |
Packaging Information: | Not provided |
Mode Of Payment: | Not provided |
Delivery Lead Time: | Not provided |
Main Sales Markets: | North America,Central/South America,Western Europe,Eastern Europe,Australasia,Asia,Middle East,Africa |
Sample Provided: | No |
Sample Policy: | Not provided |
Minimum Quantity: | Not provided |
Q-R Series Ceramic Pump Integration is designed for medium-to-high viscosity liquids, creams, and homogeneous materials (1000-100,000 CPS), as well as quantitative infusion of materials containing certain particles. This pump has high metering accuracy and repeatability, with precision better than ±0.8%. The metal part in contact with the material uses 316L stainless steel for better corrosion resistance. It adopts a quick-disassembly connection method for easy disassembly, cleaning, and meets the cleaning requirements of food hygiene standards.
Application:
It can be used for packaging machine filling and retrofitting. It is suitable for infusing medium-to-high viscosity homogeneous liquid materials such as creams, honey, electrolytes, pharmaceuticals, biochemical reagents, chemical liquids, essential oils, emulsions, perfumes, and nail polish. It can be used with multi-position bag packaging machines, multi-column packaging machines, blister packing machines, and other equipment.
Parameter:
Model | Plunger diameter |
Stroke | Volume | Accuracy | Speed | Size of the pump(mm) | |||||||
ml | CPM | A | B | C | D | E | F | G | H | ||||
Q-12R | 15 | 70 | 1-12 | ±0.5-1% | 40-60 | 521 | 117.99 | 116.50 | 50 | 30 | φ5.5 | φ26 | φ50.50 |
Q-25R | 22 | 2-25 | 521 | 117.99 | 116.50 | 50 | 30 | φ5.5 | φ26 | φ50.50 | |||
Q-50R | 30 | 5-50 | 521 | 117.99 | 116.50 | 50 | 30 | φ5.5 | φ26 | φ50.50 | |||
Q-100R | 45 | 80 | 10-100 | 588 | 139.83 | 113.18 | 90 | 35 | φ5.5 | φ32 | φ50.50 | ||
Q-200R | 50 | 110 | 20-200 | 750 | 139.83 | 113.18 | 90 | 35 | φ5.5 | φ50.50 | φ64 | ||
Q-300R | 70 | 30-300 | 750 | 139.83 | 113.18 | 90 | 35 | φ5.5 | φ50.50 | φ64 |
