Multi-sorting Checkweigher IXL-SG Series


Widely used in seafood, poultry, aquatic products, frozen products etc.





Checkweigher IXL-SG series



1. Replacing labor sorting, saving cost, improving efficiency and optimizing the production process

2. Accurate rejector systems with multi-weight zone

3. Various fast rejector systems, to satisfy rejecting unqualified products with different speed

4. 9 standard weight sorting zones , 11 weight sorting zones is available.









Specifications









Model




IXL-SG-160




IXL-SG-230S




IXL-SG-230L




IXL- SG -300







Detecting Range




10~600g




20~2000g




20~2000g




20~5000g







Scale Interval




0.05g




0.1g




0.1g




0.2g







Accuracy(??)




0.4g




0.8g




0.8g




1.5g







Detecting Speed(Max speed)




200pcs/min




160pcs/min




130pcs/min




110pcs/min







Maximum Belt Speed




60m/min




60m/min




60m/min




60m/min







The Weighed Product Size




Width




150mm




220mm




220mm




290mm







Length




200mm




250mm




350mm




400mm







Weigher Platform Size




Width




160mm




230mm




230mm




300mm







Length




280mm




350mm




450mm




500mm







Operation Screen




7-inch Touch LCD Screen







Product Storage Quantity




100 kinds







Maximum Weight Range




12 Levels







Sorter




Sorting (Optional)







Power Supply




AC220V (Optional)







Degree of Protection




IP30/IP54/IP66







Body Material




Stainless Steel (SUS304)







Note



1. The technical parameter above namely is the result of accuracy by checking only the test sample on the belt. The accuracy would be affected according to the detecting speed and product weight.

2. The detecting speed above will be affected according to the product size to be checked.

3. Requirements for different sizes by customers can be fulfilled.
